ES-16-XG

ES-16-XG

Dimensions 443 x 221 x 43 mm
Weight
Rack-Mount Brackets Included
Rack-Mount Brackets Excluded

2.71 kg
2.62 kg
Enclosure Characteristics SGCC Steel
Total Non-Blocking Throughput 160 Gbps
Switching Capacity 320 Gbps
Forwarding Rate 238.10 Mpps
Max. DC Power Consumption 36W (Excludes SFP/SFP+ Modules)
Power Method
AC
DC

100-240VAC/50-60 Hz, Universal Input
DC 56W, 25 to 16V, with 2.5 mm DC Power Inline Connector
Supported Voltage Range
AC
DC

100 to 240VAC
25 to 16VDC
Power Supply AC/DC, Internal, 56W DC
LEDs Per Data Port Speed/Link/Activity
Networking Interfaces (12) 1/10 Gbps SFP+ Ethernet Ports
(4) 1/10 Gbps RJ45 Ethernet Ports
Management Interface (1) RJ45 Serial Port, Ethernet In/Out Band
Rackmount Yes, 1U High
ESD/EMP Protection Air: ± 24 kV, Contact: ± 24 kV
Shock and Vibration ETSI300-019-1.4 Standard
Operating Temperature -5 to 40° C (23 to 104° F)
Operating Humidity 5 to 95% Noncondensing
Certifications CE, FCC, IC
